11 KV Polymer AB Switch

Get a Price/Quote

MOQ : 10 Units

11 KV Polymer AB Switch Specification

Rated Voltage
11 kV

Automation Grade
Manual

Temperature Range
-10C to +55C

Response Time
< 1 sec

Number of Module
1

Mechanical Life
More than 2000 operations

Protection Level
IP54

Max. Current
800 A

Circuit Type
Three Phase

Finish Type
Hot Dip Galvanized

Product Type
11 KV Polymer AB Switch

Material
Polymer (Silicone Rubber) & Galvanized Iron

Insulation Resistance
> 1000 M at 500V DC

Contact Resistance
< 30

Max. Voltage
12 kV

Operating Temperature
-10C to +55C

Stoke
300 mm

Size
Standard as per IS/IEC 60947

Color
Grey/Red

Weight
Approx. 24 kg

Mounting Type
Pole Mounted

Current Rating
400-800 A

No Of Poles
3

Rated Frequency
50 Hz

Minimum Clearance Phase to Earth
230 mm

Application
Outdoor Distribution Lines

Breaking Capacity
Up to 25 kA

Minimum Clearance Phase to Phase
300 mm

Closing Time
< 2 sec

Operating Mechanism
Manual Lever/Handle

Terminal Connector Type
Copper/Aluminum

Creepage Distance
320 mm minimum

Arcing Horns
Provided

Insulator Type
Polymer (Silicone Rubber)

11 KV Polymer AB Switch Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 11 KV Polymer AB Switch

Take advantage of a grand deal with our 11 KV Polymer AB Switch, a top-tier solution for outdoor distribution lines in India. Designed to handle up to 25 kA breaking capacity and rated at 11 kV and 50 Hz, this AB Switch boasts 800 A max current and rapid closing time under 2 seconds. With expert craftsmanship, it features polymer (silicone rubber) insulators, hot dip galvanized finish, copper/aluminum terminal connectors, and exceptional insulation resistance. Try now for a virtuoso addition to your infrastructure that ensures reliability and enhanced safety.

11 KV Polymer AB Switch: Extra Features and Applications

Discover the superb features of this 11 KV Polymer AB Switch, including IP54 protection level, arcing horns for added safety, and manual lever operation for precision control. Specifically designed for three-phase outdoor distribution lines, it's built to withstand harsh conditions from -10C to +55C. This switch is ideal for utility providers, rural electrification projects, and industrial environments, offering superior insulation, mechanical durability, and ease of installation on pole-mounted systems.

11 KV Polymer AB Switch: Market Reach and Certifications

Our 11 KV Polymer AB Switch is dispatched swiftly across the main domestic market of India, ensuring you benefit from the lowest price without compromising on quality. Certified to IS/IEC 60947 standards, it assures compliance and safety. Thanks to robust supply ability, we cater to large orders and also serve export markets, meeting global demand with reliable service and prompt deliveries tailored to power distribution needs.

FAQ's of 11 KV Polymer AB Switch:

Q: How does the 11 KV Polymer AB Switch enhance outdoor distribution line reliability?

A: This switch provides consistent performance with high insulation resistance, rapid response time under 1 second, and protection against adverse weather, ensuring dependable operation for outdoor power distribution.

Q: What specific applications can the 11 KV AB Switch be used for?

A: It is primarily used for three-phase outdoor distribution lines, including urban, rural, and industrial electricity distribution, offering safe manual isolation and control of high-voltage circuits.

Q: When should the AB switch be operated, and what are its key operation features?

A: Operate the switch as part of routine isolation or emergency cut-off procedures. The manual lever/handle mechanism allows safe and quick operation, with a closing time of less than 2 seconds and more than 2000 mechanical operations life.

Q: Where is the 11 KV Polymer AB Switch typically installed?

A: It is normally pole-mounted outdoors on distribution networks where reliable switchgear is essential, with required clearances between phases and to earth for safety.

Q: What is the benefit of arcing horns and IP54 protection in this AB Switch?

A: Arcing horns safely manage electrical arcs during switching, prolonging the device lifespan, while IP54 protection defends against dust and moisture ingress, ensuring durable performance.

Q: How is the AB Switch dispatched and what markets does it serve?

A: Products are dispatched promptly to domestic clients across India and are available for export, ensuring both local and global power distribution needs are efficiently fulfilled.
